The peanut three-roller half cutting machine is a professional nut processing machine designed specifically for splitting whole peanuts into uniform halves while minimizing breakage and material loss. With a stable capacity of up to 1000 kg/h, this machine is widely used in peanut snack processing, confectionery production, and peanut ingredient manufacturing.
Equipped with a three-roller cutting system and an integrated air-separation unit, this peanut half cutting machine delivers clean, evenly split peanut halves with high efficiency and consistent quality.
Watch the Video of the peeling and half cutting machine
Application of the peanut cutting machine
This industrial peanut half-cutting machine is suitable for:
- Peanut half kernel production
- Coated peanuts and sugar-coated snacks
- Bakery and confectionery ingredients
- Peanut brittle, candy, and chocolate fillings
- Food factories requiring uniform peanut halves
It is especially ideal for applications where appearance, size consistency, and low breakage rate are critical.
The peanut peeler can also match with other machines to use in a peanut butter production line.
Working Principle of peanut skin peeling machine
The machine is composed of a feeding hopper, three rollers, two layers of vibrating screen conveyor, a centrifugal fan, and an outlet.
Three rollers inside the peeler squeeze peanuts and divide the nuts into halves under differential motion. During the vibration-conveying process, the detached skins are separated by a low-pressure fan.
It could remove the red skin of peanuts, cut peanuts in half, and separate the embryos.
Machine Parameter
| Type | Power | Fan power | Capacity | Size | voltage |
| 500kg | 1.5kw | 1.5kw | 500-600kg/h | 1.9mx0.85mx1.35m | 380v |
| 1000kg | 2.2kw | 1.5kw | 1000kg/h | 1.9mx1.15mx1.35m | 380v |
As you can see, we have two different peanut cutting machines for you to choose from. The size of the machine, fan power, and voltage are the same, but the difference is the output.
One is 500-600 kg/h, and the other is 1000 kg/h. You can choose according to your needs. If you have any questions, you can contact us at any time, and we will reply to you as soon as possible.
Advantages of three roller peanut peeling machine
- Multi-functions
The peanut half-parting machine has three effects: peeling, cutting in half, and removing embryos. So the processed peanuts could produce better peanut butter, with no bitter flavor, because the embryo may damage the taste of the peanut butter.
- Large output
We provide 500kg and 1000kg peanut peeling machines. And customers could also make a specific output.
- Wide application
The peanut red skin peeling machine could be used as a single machine or in a production line. It is also an important machine in the cocoa bean processing line.
Operation Precautions of dry peanut cutting machine
- Before starting the machine, check whether the circuit is functioning properly and whether the components are secure and in good condition.
- The processed peanuts must not contain stones and other debris.
- Adjust the insert plate of the upper hopper to a suitable position, and control the unloading speed to ensure the peeling effect of the equipment.
- Control the gap between the three rubber rollers appropriately according to the size of the peanuts. Generally, the gap between the upper and middle rollers is 8-10 mm, and the gap between the middle and lower rollers is 5-8 mm.
- Start the fan, and the three rollers squeeze peanuts to remove the skin. And the centrifugal fan sucks out the broken skin.
- After finishing each operation, clean the oil on the equipment to ensure the sanitary quality of the half-grain.
Machine Maintenance
- Frequently check the circuit control system, whether the rotating system is normal, and whether the fastening bolts are loose. The parts to be lubricated should be filled with oil frequently.
- The inside of the rubber roller box should be cleaned regularly, and attention should be paid to hygiene. The three rollers are replaced every three years.
- The inside of the suction fan should be cleaned frequently to ensure smooth suction and dust removal.
Contact Us!
If you are looking for a professional peanut three-roller half cutting machine or need a complete peanut processing solution, please contact us.
Our technical team can help you:
- Select the right equipment for your capacity
- Optimize your peanut processing workflow
- Integrate machines into your existing production line
Contact us today to receive expert advice and a customized solution.
